ADUM3402

ADI

Quad-Channel, Digital Isolator, Enhanced System-Level ESD Reliability

Наличие: 1,170 шт. Гарантия оригинала

Адрес доставки: Москва

Цена: Запросить цену

шт.

Купить

Цена действительна 24 часа

Высокий спрос на этой неделе

Производитель:

ADI

ЧипСити Номер продукта:

CC389469287

Дата доставки: 7 дней

3D модель

Оплата:

Обновлено 01.05.2026, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

Более 11 лет опыта в закупках

Сертифицированный поставщик (ISO)

1000+ клиентов в России

Поддержка малого MOQ

ADUM3402 характеристики

Атрибут	Значение атрибута
Номенклатура	ADUM3402
Производитель	ADI
ЧипСити Номер продукта	CC389469287
Жизненный Цикл Продукта	Active
Даташит
3D модель	3D модель
RoHS Комплаенс	RoHS Compliant
	Показывать Просмотр аналоги замена

Аналоги товара

ADUM3402 описание продукта

Product Details
The ADuM3400/ADuM3401/ADuM3402 are 4-channel digital isolators based on the Analog Devices, Inc., iCoupler® technology. Combining high speed CMOS and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices.
iCoupler devices remove the design difficulties commonly associated with optocouplers. Typical optocoupler concerns regarding uncertain current transfer ratios, nonlinear transfer functions, and temperature and lifetime effects are eliminated with the simple iCoupler digital interfaces and stable performance characteristics. The need for external drivers and other discrete components is eliminated with these iCoupler products. Furthermore, iCoupler devices consume one-tenth to one-sixth the power of optocouplers at comparable signal data rates.
The isolators provide four independent isolation channels in a variety of channel configurations and data rates (see the Ordering Guide). All models operate with the supply voltage on either side ranging from 2.7 V to 5.5 V, providing compatibility with lower voltage systems as well as enabling a voltage translation functionality across the isolation barrier. The isolators have a patented refresh feature that ensures dc correctness in the absence of input logic transitions and during powerup/power-down conditions.
In comparison to the ADuM1400/ADuM1401/ADuM1402 isolators, the ADuM3400/ADuM3401/ADuM3402 isolators contain various circuit and layout changes to provide increased capability relative to system-level IEC 61000-4-x testing (ESD/ burst/surge). The precise capability in these tests for either set of isolators is strongly determined by the design and layout of the user’s board or module. For more information, see the AN-793 application note, ESD/Latch-Up Considerations with _i_Coupler Isolation Products.
**Applications**
General-purpose multichannel isolation
SPI/data converter isolation
RS-232/RS-422/RS-485 transceivers
Industrial field bus isolation
### Features and Benefits
For AEC-Q100 Automotive Qualified Devices Specifications view ADuM340xW data sheet
Enhanced system-level ESD performance per IEC 61000-4-x
Bidirectional communication
3 V/5 V level translation
High temperature operation: 105°C
High data rate: dc to 90 Mbps (NRZ)
See data sheet for additional features
**ADuM3402-EP supports defense and aerospace applications (AQEC standard)**
Download ADuM3402-EP data sheet (pdf)
Military temperature range (−55°C to +125°C)
Controlled manufacturing baseline
One assembly/test site
One fabrication site
Enhanced product change notification
Qualification data available on request
V62/14631 DSCC Drawing Number

Показывать

ADUM3402 Даташит PDF

25 страницы, 148 КБ

09/10/2015
