PCA8574APW

NXP

I2C GPIO Expander 5.5V 16Pin TSSOP

Наличие: 1,058 шт. Гарантия оригинала

Адрес доставки:

Цена: ₽ 267.56

шт.

Купить

Цена действительна 24 часа

Высокий спрос на этой неделе

Производитель:

NXP

ЧипСити Номер продукта:

CC121981734

Дата доставки: 7 дней

3D модель

Оплата:

Обновлено 01.05.2026, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

Более 11 лет опыта в закупках

Сертифицированный поставщик (ISO)

1000+ клиентов в России

Поддержка малого MOQ

PCA8574APW характеристики

Атрибут	Значение атрибута
Номенклатура	PCA8574APW
Производитель	NXP
ЧипСити Номер продукта	CC121981734
Жизненный Цикл Продукта	В производстве
Даташит
3D модель	3D модель
Стиль Монтажа	Surface Mount
Количество Выводов	16 Pin
Корпус/Пакет	TSSOP-16
Упаковка	Tube
RoHS Комплаенс	RoHS Compliant
Бессвинцовая Статус	Lead Free
	Показывать Просмотр аналоги замена

Аналоги товара

PCA8574APW описание продукта

Overview
The PCA8574/74A provides general-purpose remote I/O expansion via the two-wire bidirectional I²C‑bus (serial clock (SCL), serial data (SDA)).
The devices consist of eight quasi-bidirectional ports, 400 kHz I²C‑bus interface, three hardware address inputs and interrupt output operating between 2.3 V and 5.5 V. The quasi-bidirectional port can be independently assigned as an input to monitor interrupt status or keypads, or as an output to activate indicator devices such as LEDs. The system master can read from the input port or write to the output port through a single register.
The low current consumption of 4.5 μA (typical, static) is great for mobile applications and the latched output ports have 25 mA high current sink drive capability for directly driving LEDs.
The PCA8574 and PCA8574A are identical, except for the different fixed portion of the slave address. The three hardware address pins allow eight of each device to be on the same I²C‑bus, so there can be up to 16 of these I/O expanders PCA8574/74A together on the same I²C‑bus, supporting up to 128 I/Os (for example, 128 LEDs).
The active LOW open-drain interrupt output (INT) can be connected to the interrupt logic of the microcontroller and is activated when any input state differs from its corresponding input port register state. It is used to indicate to the microcontroller that an input state has changed and the device needs to be interrogated without the microcontroller continuously polling the input register via the I²C‑bus.
The internal Power-On Reset (POR) initializes the I/Os as inputs with a weak internal pull-up 100 μA current source.
MoreLess
## Features
* I²C‑bus to parallel port expander
* 400 kHz I²C‑bus interface (Fast-mode I²C‑bus)
* Operating supply voltage 2.3 V to 5.5 V with 5.5 V tolerant I/Os held to VDD with 100 μA current source
* 8-bit remote I/O pins that default to inputs at power-up
* Latched outputs with 25 mA sink capability for directly driving LEDs
* Total package sink capability of 200 mA
* Active LOW open-drain interrupt output
* Eight programmable slave addresses using three address pins
* Low standby current (4.5 μA typical)
* -40 °C to +85 °C operation
* ESD protection exceeds 2000 V HBM per JESD22-A114 and 1000 V CDM per JESD22-C101
* Latch-up testing is done to JEDEC standard JESD78 which exceeds 100 mA
* Packages offered: SO16, TSSOP16, SSOP20
## Target Applications
* LED signs and displays
* Servers
* Key pads
* Industrial control
* Medical equipment
* PLCs
* Cellular telephones
* Gaming machines
* Instrumentation and test measurement
## Features

Показывать

PCA8574APW Даташит PDF

8 страницы, 3541 КБ

07/29/2014
