ANALOG DEVICES ADG732BCPZ 32:1 Analog Multiplexer IC, Single, 5.5Ω, 1.8V to 5.5V, LFCSP-48

Наличие: 1,166 шт.

Адрес доставки: Москва

Цена: ₽ 1,202.50

шт.

Купить

*Запросить предложение по оптовому количеству?

*Акции меняются очень быстро Контакты немедленно!

Производитель:

ADI

ЧипСити Номер продукта:

CC1442204

Категория продукта:

Мультиплексор

3D модель

Оплата:

Обновлено 17.06.2025, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

ADG732BCPZ характеристики

Атрибут	Значение атрибута
Номенклатура	ADG732BCPZ
Производитель	ADI
ЧипСити Номер продукта	CC1442204
Категория продукта	Мультиплексор
Даташит
3D модель	3D модель
Стиль Монтажа	Surface Mount
Количество Выводов	48 Pin
Корпус/Пакет	LFCSP-48
Количество Выходных Интерфейсов	1 Output
Ток Питания	10 µA
Количество Цепей	1 Circuit
Количество Каналов	32 Channel
Количество Стежков	48 Position
Рассеяние Мощности	100 µW
Ширина Ленты	18 MHz
Количество входов	32 Input
Рабочая температура (Макс)	85 ℃
Рабочая температура (мин)	-40 ℃
Полоса пропускания 3 дБ	18 MHz
Длина	7 mm
Ширина	7 mm
Высота	0.83 mm
Рабочая Температура	-40℃ ~ 85℃
Жизненный Цикл Продукта	Active
Упаковка	Tray
RoHS Комплаенс	RoHS Compliant
Бессвинцовая Статус	Contains Lead
REACH SVHC Комплаенс	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN кодекс	EAR99
	Показывать Просмотр аналоги замена

ADG732BCPZ описание продукта

Product Details
The ADG726/ADG732 are monolithic, complementary metal oxide semiconductor (CMOS) 32-channel and dual 16-channel analog multiplexers. The ADG732 switches one of 32 inputs (S1 to S32) to a common output, D, as determined by the 5-bit binary address lines A0, A1, A2, A3, and A4. The ADG726 switches one of 16 inputs as determined by the 4-bit binary address lines A0, A1, A2, and A3.
On-chip latches facilitate microprocessor interfacing. The ADG726 may also be configured for differential operation by tying CSA and CSB together. An EN input is used to enable or disable the devices. When disabled, all channels are switched off.
These multiplexers are designed on an enhanced submicron process that provides low power dissipation yet gives high switching speed, very low on resistance, and leakage currents. They operate from a single supply of +1.8 V to +5.5 V and a ±2.5 V dual supply, making them ideally suited to a variety of applications. On resistance is in the region of a few ohms and is closely matched between switches and very flat over the full signal range. These devices can operate equally well as either multiplexers or demultiplexers and have an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. All channels exhibit break-before-make switching action, preventing momentary shorting when switching channels.
The ADG726/ADG732 are available in a 48-lead LFCSP or a 48-lead TQFP. For functionally equivalent devices with serial interface, see the ADG725/ADG731.
Product Highlights
1. +1.8 V to +5.5 V single- or ±2.5 V dual-supply operation.
These devices are specified and guaranteed with +5 V ± 10%, +3 V ± 10% single-supply, and ±2.5 V ± 10% dual-supply rails.
2. An on resistance of 4 Ω.
3. Guaranteed break-before-make switching action.
4. 48-lead LFCSP package or 48-lead TQFP package.
Applications
Optical applications
Data acquisition systems
Communication systems
Relay replacement
Audio and video switching
Battery-powered systems
Medical instrumentation
Automatic test equipment (ATE)
### Features and Benefits
1.8 V to 5.5 V single-supply operation
±2.5 V dual-supply operation
On resistance: 4 Ω at 25°C (+5 V single supply/±2.5 V dual supply)
0.5 Ω on-resistance flatness at 25°C (+5 V single supply/ ±2.5 V dual supply)
Rail-to-rail operation
Transition times: 23 ns typical at 25°C
Single 32-to-1 channel multiplexer
Dual/differential 16-to-1 channel multiplexer
TTL-/CMOS-compatible inputs
48-lead TQFP or 48-lead, 7 mm × 7 mm LFCSP

Показывать

ADG732BCPZ Даташит PDF

21 страницы, 445 КБ

06/23/2015
