STM8AF5286UDX

ST Microelectronics

STMICROELECTRONICS STM8AF5286UDX 8Bit Microcontroller, Automotive, STM8AF, 24MHz, 64KB, 6KB, 32Pins, VFQFPN

Наличие: 278 шт. Гарантия оригинала

Адрес доставки:

Цена: ₽ 238.33

шт.

Купить

Цена действительна 24 часа

Высокий спрос на этой неделе

Производитель:

ST Microelectronics

ЧипСити Номер продукта:

CC107926896

Категория продукта:

Микроконтроллер 8

Дата доставки: 7 дней

3D модель

Оплата:

Обновлено 01.05.2026, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

Более 11 лет опыта в закупках

Сертифицированный поставщик (ISO)

1000+ клиентов в России

Поддержка малого MOQ

STM8AF5286UDX характеристики

Атрибут	Значение атрибута
Номенклатура	STM8AF5286UDX
Производитель	ST Microelectronics
ЧипСити Номер продукта	CC107926896
Жизненный Цикл Продукта	Active
Категория продукта	Микроконтроллер 8
Даташит
3D модель	3D модель
Количество Выводов	32 Pin
Корпус/Пакет	UFQFN-32
Количество Стежков	32 Position
Тактовая Частота	24.0 MHz
Размер ОЗУ	6 KB
Количество АЦП	1 ADC
Количество входов и выходов	25 Input IO
Рабочая температура (Макс)	150 ℃
Рабочая температура (мин)	-40 ℃
Напряжение питания (Макс)	5.5 V
Напряжение питания (мин)	3 V
Рабочая Температура	-40℃ ~ 150℃ (TA)
Упаковка	Each
RoHS Комплаенс	RoHS Compliant
Бессвинцовая Статус
REACH SVHC Compliance Edition	2015/12/17
ECCN кодекс	EAR99
	Показывать Просмотр аналоги замена

Аналоги товара

STM8AF5286UDX описание продукта

The STM8AF526x/8x/Ax and STM8AF6269/8x/Ax automotive 8-bit microcontrollers described in this datasheet offer from 32 Kbyte to 128 Kbyte of non volatile memory and integrated true data EEPROM. They are referred to as high density STM8A devices in STM8S series and STM8AF series 8-bit microcontrollers reference manual (RM0016).
The STM8AF52 series features a CAN interface.
All devices of the STM8A product line provide the following benefits: reduced system cost, performance and robustness, short development cycles, and product longevity.
The system cost is reduced thanks to an integrated true data EEPROM for up to 300 k write/erase cycles and a high system integration level with internal clock oscillators, wtachdog, and brown-out reset.
Device performance is ensured by 20 MIPS at 24 MHz CPU clock frequency and enhanced characteristics which include robust I/O, independent watchdogs (with a separate clock source), and a clock security system.
Short development cycles are guaranteed due to application scalability across a common family product architecture with compatible pinout, memory map, and modular peripherals. Full documentation is offered with a wide choice of development tools.
Product longevity is ensured in the STM8A family thanks to their advanced core which is made in a state-of-the art technology for automotive applications with 3.3 V to 5.5 V operating supply.
All STM8A and ST7 microcontrollers are supported by the same tools including STVD/STVP development environment, the STice emulator and a low-cost, third party in-circuit debugging tool.
**Key Features**
AEC-Q10x qualified
Core
Max fCPU : 24 MHz
Advanced STM8A core with Harvard architecture and 3-stage pipeline
Average 1.6 cycles/instruction resulting in 10 MIPS at 16 MHz fCPU for industry standard benchmark
Memories
Program memory: 32 to 128 Kbyte Flash program; data retention 20 years at 55 °C
Data memory: up to 2 Kbyte true data EEPROM; endurance 300 kcycle
RAM: 6 Kbyte
Clock management
Low-power crystal resonator oscillator with external clock input
Internal, user-trimmable 16 MHz RC and low-power 128 kHz RC oscillators
Clock security system with clock monitor
Reset and supply management
Wait/auto-wakeup/Halt low-power modes with user definable clock gating
Low consumption power-on and power-down reset
Interrupt management
Nested interrupt controller with 32 vectors
Up to 37 external interrupts on 5 vectors
Timers
2 general purpose 16-bit timers with up to 3 CAPCOM channels each (IC, OC, PWM)
Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization
8-bit AR basic timer with 8-bit prescaler
Auto-wakeup timer
Window and independent watchdog timers
I/Os
Up to 68 user pins (11 high sink I/Os)
Highly robust I/O design, immune against current injection
Communication interfaces
High speed 1 Mbit/s CAN 2.0B interface
USART with clock output for synchronous operation - LIN master mode
LINUART LIN 2.2 compliant, master/slave modes with automatic resynchronization
SPI interface up to 10 Mbit/s or fMASTER /2
I2 C interface up to 400 Kbit/s
Analog to digital converter (ADC)
10-bit resolution, 2 LSB TUE, 1 LSB linearity and up to 16 multiplexed channels
Operating temperature up to 150 °C
Qualification conforms to AEC-Q100 grade 0

Показывать

STM8AF5286UDX Даташит PDF

122 страницы, 1524 КБ

06/09/2015
