Картинки только для справки.Точные характеристики следует получить из паспорта продукта.

S9S08AW60E5MFDE

NXP

MCU 8Bit HCS08 CISC 60KB Flash 3.3V/5V 48Pin QFN EP Tray

Наличие: 242 шт. Гарантия оригинала

Адрес доставки:

Цена: ₽ 270.13

шт.

Купить

Цена действительна 24 часа

Высокий спрос на этой неделе

Производитель:

NXP

ЧипСити Номер продукта:

CC171426026

Категория продукта:

Микроконтроллер

Дата доставки: 7 дней

3D модель

Оплата:

Обновлено 26.04.2026, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

Более 11 лет опыта в закупках

Сертифицированный поставщик (ISO)

1000+ клиентов в России

Поддержка малого MOQ

S9S08AW60E5MFDE характеристики

Атрибут	Значение атрибута
Номенклатура	S9S08AW60E5MFDE
Производитель	NXP
ЧипСити Номер продукта	CC171426026
Жизненный Цикл Продукта	Active
Категория продукта	Микроконтроллер
Даташит
3D модель	3D модель
Стиль Монтажа	Surface Mount
Количество Выводов	48 Pin
Корпус/Пакет	QFN-48
Безгалогеновый Статус	Halogen Free
Тактовая Частота	40.0 MHz
Размер ОЗУ	2 KB
Размер Флэш-памяти	60 kB
Количество АЦП	1 ADC
Рабочая температура (Макс)	125 ℃
Рабочая температура (мин)	-40 ℃
Напряжение питания (Макс)	5.5 V
Напряжение питания (мин)	2.7 V
Вес	112.3 mg
Рабочая Температура	-40℃ ~ 125℃
Упаковка	Each
RoHS Комплаенс	RoHS Compliant
Бессвинцовая Статус	Lead Free
REACH SVHC Комплаенс	No SVHC
REACH SVHC Compliance Edition	2015/12/17
	Показывать Просмотр аналоги замена

Аналоги товара

S9S08AW60E5MFDE описание продукта

Overview
The MC9S08AW60, MC9S08AW48, MC9S08AW32 and MC9S08AW16 are members of the low-cost, high-performance HCS08 family of 8-bit microcontroller units (MCUs). All MCUs in the family use the enhanced S08 core and are available with a variety of modules, memory sizes, memory and package types. MC9S08AW microcontrollers support both the Industrial and Automotive industry.
MoreLess
## Features
### 8-bit HCS08 CPU Core
* 8-bit HCS08 CPU Core
* 50 ns minimum instruction cycle time down to 2.7V @ 20 MHz bus
* C-optimized architecture with multiply and divide instructions
* Optional power modes
* Support for up to 32 interrupt/reset sources allows for greater software flexibility and optimization
* Optional auto wake-up from Stop 2 or Stop 3 modes with internal timer typically requires only 300 nA additional current
### On-Chip Debug Interface
* Single-wire background debug mode
* On-chip trace buffer with nine flexible trigger modes and multiple hardware breakpoints
* Nonintrusive emulation
### Integrated Third-Generation Flash Memory
* In-application reprogrammable
* Self-timed, fast programming
* Can program 8 bits in 20 µs
* Fast Flash page erase
* 20 ms (512 bytes)
* 10K write/erase cycles minimum, 100K typical
* 15-year minimum data retention, 100 years typical
* Internal program/erase voltage generation
* Fine Flash granularity—512B Flash erase/1B Flash program
* Flexible block protection and enhanced security
* Single power supply program/erase
* Read/program/erase over full operation voltage and temperature
### Internal Clock Generator
* Programmable frequency-locked loop (FLL) generates 8 MHz to 40 MHz (for bus rates up to 20 MHz)
* Post-FLL divider gives one of eight bus rate dividers
* Trimmable with temperature and voltage compensation
* Provides multiple options for clock sources and in-application clock switching
* 32 KHz to 16 MHz reference external crystal/resonator
* Internal clock generator
* External clock
### 10-bit Analog-to-Digital Converter (ADC)
* 16-channel ADC
* 2.5 µs, 10-bit single conversion time
### Timer with Eight Programmable Channels
* 2-channel and 6-channel, 16-bit timer systems
* Each channel programmable for
* Input capture, output compare or buffered pulse-width modulator (PWM)
* PWM can be edge- or center-aligned
* 16-bit free-running or up/down (CPWM) count operation
### Extensive Serial Communications
* Dual asynchronous SCIs
* Flexible 13-bit module-based baud rate generators
* Double-buffered receive and transmit
* LIN compatible
* Synchronous SPI
* Up to 5 Mbps
* Inter-IC (I2C) bus
* Multimaster operation
* 256 clock options
### System Protection
* Selectable low-voltage detect/reset
* Enhanced low-voltage warning
* COP watchdog timer
### Up to 56 Input/Output (I/O) Lines
* Programmable pull-ups
* High-current drivers
* Eight keyboard interrupts
* Controlled rise/fall times minimize noise
### Product Longevity Program
* This product is included in NXP®.s product longevity program, with assured supply for a minimum of 15 years after launch
* This product is included in NXP®.s product longevity program, with assured supply for a minimum of 15 years after launchComparison Table
### S08AW Family Comparison
| S08AWxA Family| S08AW Family| S08AC Family
| |
| |
| |
| |
| |
| |
*EEPROM can be emulated with flash. Go to related Application Notes.
The 48-pin package includes one 8 ADC channels, 7 KBI ports, 38 I/O pins and a 4-ch timer (instead of 6)
The 44-pin package includes one 8 ADC channels, 6 KBI ports, 34 I/O pins and a 4-ch timer (instead of 6)

Показывать

S9S08AW60E5MFDE Даташит PDF

4 страницы, 164 КБ

10/30/2013
