Картинки только для справки.Точные характеристики следует получить из паспорта продукта.

PCT2075GVX

NXP

PCT2075 Series 2.7 to 5.5V Temperature Sensor Surface Mount - TSOP-6

Наличие: 40,703 шт.

Адрес доставки: Москва

Цена: ₽ 78.39

шт.

Купить

*Запросить предложение по оптовому количеству?

*Акции меняются очень быстро Контакты немедленно!

Производитель:

NXP

ЧипСити Номер продукта:

CC7166741

Категория продукта:

Датчики Температуры

3D модель

Оплата:

Обновлено 17.06.2025, 07:48:07(GMT+3)

Проверка качества компонентов

тдел качества компонентов ЧипСити поддерживает вышеупомянутые многочисленные методы проверки, чтобы гарантировать качество компонентов. Узнать больше >

PCT2075GVX характеристики

Атрибут	Значение атрибута
Номенклатура	PCT2075GVX
Производитель	NXP
ЧипСити Номер продукта	CC7166741
Категория продукта	Датчики Температуры
Даташит
3D модель	3D модель
Стиль Монтажа	Surface Mount
Количество Выводов	6 Pin
Корпус/Пакет	TSOP-6
Ток Питания	0.4 mA
Количество Стежков	6 Position
Рабочая температура (Макс)	125 ℃
Рабочая температура (мин)	-55 ℃
точность	±2 ℃
Напряжение питания	2.7V ~ 5.5V
Напряжение питания (Макс)	5.5 V
Напряжение питания (мин)	2.7 V
Рабочая Температура	-55℃ ~ 125℃
Жизненный Цикл Продукта	Active
Упаковка	Tape & Reel (TR)
RoHS Комплаенс	RoHS Compliant
Бессвинцовая Статус	Lead Free
ECCN кодекс	EAR99
	Показывать Просмотр аналоги замена

PCT2075GVX описание продукта

Overview
The PCT2075 is a temperature-to-digital converter featuring ±1 °C accuracy over ‑25 °C to +100 °C range. It uses an on-chip band gap temperature sensor and Sigma-Delta A‑to‑D conversion technique with an overtemperature detection output that is a drop-in replacement for other LM75 series thermal sensors. The device contains a number of data registers: Configuration register (Conf) to store the device settings such as device operation mode, OS operation mode, OS polarity and OS fault queue; temperature register (Temp) to store the digital temp reading, set-point registers (Tos and Thyst) to store programmable overtemperature shutdown and hysteresis limits, and programmable temperature sensor sampling time Tidle, that can be communicated by a controller via the 2-wire serial I²C-bus Fast-mode Plus interface.
The PCT2075 also includes an open-drain output (OS) which becomes active when the temperature exceeds the programmed limits. The OS output operates in either of two selectable modes: OS comparator mode or OS interrupt mode. Its active state can be selected as either HIGH or LOW. The fault queue that defines the number of consecutive faults in order to activate the OS output is programmable as well as the set-point limits.
The PCT2075 can be configured for different operation conditions. It can be set in normal mode to periodically monitor the ambient temperature, or in shut-down mode to minimize power consumption.
The temperature register always stores an 11-bit two’s complement data, giving a temperature resolution of 0.125 °C. This high temperature resolution is particularly useful in applications of measuring precisely the thermal drift or runaway. When the device is accessed the conversion in process is not interrupted (that is, the I²C-bus section is totally independent of the Sigma-Delta converter section) and accessing the device continuously without waiting at least one conversion time between communications will not prevent the device from updating the Temp register with a new conversion result. The new conversion result will be available immediately after the Temp register is updated. It is also possible to read just one of the temperature register bytes without lock-up.
The PCT2075 powers up in the normal operation mode with the OS in comparator mode, temperature threshold of 80 °C and hysteresis of 75 °C, so that it can be used as a stand-alone thermostat with those pre-defined temperature set points. The default set points can be modified during manufacture and ordered under custom part number.
There are three selectable logic address pins with three logic states so that 27 8-pin devices or three 6-pin devices can be connected on the same bus without address conflict.
MoreLess
## Features
* Pin-for-pin replacement for LM75 series but allows up to 27 devices on the bus
* Power supply range from 2.7 V to 5.5 V
* Temperatures range from -55 °C to +125 °C
* Frequency range 20 kHz to 1 MHz with SMBus time-out to prevent hanging up the bus
* 1 MHz Fast-mode Plus 30 mA SDA drive allows more devices on the same bus but is backward compatible to Fast-mode and Standard-mode
* 11-bit ADC that offers a temperature resolution of 0.125 °C
* Temperature accuracy of:
* ±1 °C (max.) from -25 °C to +100 °C
* ±2 °C (max.) from -55 °C to +125 °C
* Programmable temperature threshold and hysteresis set points during operation
* Supply current of <1.0 μA in shut-down mode for power conservation
* Stand-alone operation as thermostat at power-up
* ESD protection exceeds 2000 V HBM per JESD22-A114 and 1000 V CDM per JESD22-C101
* Latch-up testing is done to JEDEC Standard JESD78 which exceeds 100 mA
* Small 8-pin package types: SO8, TSSOP8 and 2 mm x 3 mm HWSON8
* Small 6-pin package type: TSOP6
