| Атрибут | Значение атрибута | |
|---|---|---|
| Номенклатура | AFG3011 | |
| Производитель | Tektronix | |
| ЧипСити Номер продукта | CC540191972 | |
| Категория продукта | Сигнал-генератор | |
| Даташит | Datasheet | |
| Частота | 10 MHz | |
| Количество Каналов | 1 Channel | |
| Brand/Series | AFG3000 Series | |
| Configuration | Bench | |
| Connection | LAN, USB, GPIB | |
| Dimensions | 6.2" H x 13.0" W x 6.6" D | |
| Display | 5.6" Color LCD | |
| Frequency | 10 MHz | |
| Frequency, Output | 4.9 MHz (4.9 MHz to 50 MHz: a fraction of the frequency is output; >50 MHz: no signal is output) | |
| Function | Sine, Square, Triangle, Pulse, Ramp, DC, Noise, sin(x)/x, Exponential, Gaussian, Lorentz, Haversine, Arb. | |
| Impedance, Output | 50 Ω, AC Coupled | |
| Includes | Quick-start user manual, power cord, USB cable, CD-ROM with programmer manual, service manual, LabView™ and IVI drivers, CD-ROM with ArbExpress® software, NIST-traceable calibration certificate. | |
| Memory | 128 Kpts | |
| Modulation Type | AM, FM, PM, FSK, PWM | |
| Number of Channels | 1 | |
| Power Dissipation | Less than 120 W | |
| Power Source | 100 to 240 V, 47 to 63 Hz or 115 V, 360 to 440 Hz | |
| Range | (Continuous Mode): 0 ps to Period, (Triggered/Gated Burst Mode): 0 ps to Period – [Pulse Width + 0.8 *(Leading Edge Time + Trailing Edge Time)] | |
| Resolution | 10 ps or 8 digits | |
| Sample Rate | 250 MS/s | |
| Time, Fall | and Rise ≤50 ns | |
| Type | Function/Arb. Waveform | |
| Waveform | 10 MHz, 25 MHz, 100 MHz or 240 MHz sine waveforms | |
| Weight | 9.9 Lbs. | |
|
